5041-4.5t 70k/80k Truck Mounted Attenuator Vehicle

The 5041 type 80K Truck Mounted Attenuator Vehicle is mainly used for safety protection in road maintenance and construction operations. The vehicle is parked behind a temporarily closed construction area and absorbs the kinetic energy of the vehicle from the rear collision through the anti-collision buffer pad, providing effective protection for workers and equipment in the construction area, while maximizing the personal safety of personnel in the rear collision vehicle.

Send email to us

Product Detail

PRODUCT PARAMETER

Product Tags

International mutual recognition

90° foldable, reduce wind resistance while driving

Reliable performance

Well-known brand chassis

5041

80K Truck Mounted Attenuator Vehicle

80K Truck Mounted Attenuator (TMA) Vehicle is designed to provide critical safety protection for road maintenance, utility, and construction operations. Positioned behind temporary work zones or lane closures, the TMA system absorbs and dissipates the impact energy of errant vehicles, helping to protect workers, equipment, and construction vehicles while reducing collision severity and enhancing occupant safety.

Equipped with a high-performance 80K-rated Truck Mounted Attenuator system, the vehicle delivers reliable work-zone protection and is suitable for highways, expressways, urban roads, airports, and other traffic management applications. The system is safe, dependable, and easy to operate, making it an ideal solution for temporary traffic control and roadwork safety.

Before

After

PRODUCT DESCRIPTION

Large warning light signs

So that the vehicles behind can see the warning lights from a farther distance, improve vigilance and reduce accidents.

Appearance Optimization

The attenuator features an optimized structural design for enhanced durability and appearance. Its surface is protected by a 3 mm double-layer coating system, with a durable rubberized outer finish that provides excellent resistance to scratches, corrosion, and debris impact. Rounded corner protection further improves durability by reducing the risk of edge damage and minimizing secondary impacts caused by collisions.

Efficient and Rapid Deployment

The attenuator is raised and lowered by a hydraulic cylinder system, with hydraulic power supplied through the vehicle's electro-hydraulic control system. The deployment and stowing process can be completed in as little as 11 seconds, enabling quick setup and removal while improving operational efficiency and reducing work-zone preparation time.

Aerospace grade aluminum honeycomb core

The outer shell of the crash pad is made of lightweight aluminum alloy flexible material, and the interior is made of aerospace-grade honeycomb aluminum energy-absorbing material, which can efficiently absorb energy.

Reversing image assistance

The camera is installed at the rear of the vehicle and the display screen is installed in the cab. When reversing, the driver can always observe the situation behind the vehicle to ensure reversing safety.

Foldable seat cushion

The bumper can be folded 90 degrees, reducing the risk during driving and making travel more convenient.

Easy to install

Truck Mounted Attenuator Vehicle connects the seat cushion to the vehicle through a special connector, which can be connected to the vehicle within 2 hours, which is simple and convenient.

SCOPE OF APPLICATION

This equipment is suitable for the daily maintenance of highways, national and provincial trunk roads and municipal roads and the safety protection of emergency rescue.
